Key Specifications/Special Features:

• Fanless Design
• Intel Bay Trail-D J1900 CPU built-in
• 8 x COM (opional)
• 8 x LAN (optional)

Specifications:

CPU	Intel® Bay Trail-D J1900 SoC Processor
BIOS	AMI UEFI
Memory	On CH SO-DIMM / DDR3L 1333/1066MHz(Max. up to 8GB)
Storage	2.5” SATA Device * 1 m-SATA SSD (mini-PCIE Slot)*1
Colors	Black
Front I/O Port	Power SW *1 HDD LED *1 COM*8 (optional) Intel Giga LAN *8 (optional)
Rear I/O Port	USB3.0 *1, USB2.0 *3 VGA *1, HDMI *1 Giga LAN *2 MIC *1, Line out *1 COM *1 DC-in Jack *1 Reset SW *1 WiFi Port *2 (optional)
Power Source	AC 90~240V/60W/DC-12V Adapter/Lock
Expansion Interface	Mini PCI-E *2(Full-size)
Operating Temperature	0~60°C
Storage Temperature	-10~70°C
Net weight(Kgs)	2.4 Kg
Dimension	18.5 * 16.5 * 4.8 cm
