News/TOPSCCC news



Dec/5/2019 EX5000 series:
EX-5000 is a series of data acquisition modules. It provides a total solution of the data acquisition network and control system. Including the communication modules, the analog input modules, the analog output modules, and the digital I/O modules. You can remotely control up to 256 EX modules on USB/RS-485/Ethernet network.

Digital Input & Output Modules:
EX-5028
8-ch MOSEFT Output and 24-ch Isolated Digital Input Module
EX-5029
16 Isolated MOSFET Output and 16-ch Isolated Digital Input Module
EX-5060
10-ch Relay and 12-ch Isolated Digital Input Module

Analog I/O series:
EX-5015
12-channels RTD Input Module (Resolution 16 bits)
EX-5017
16-channels Analog Input Module with 2-ch Isolated Digital Input and 1-ch Digital Output (Resolution 16 bits)
EX-5019
16-ch Thermocouple Input Module With 2-ch Isolated Digital Input and 1-ch Digital Output(Resolution 16 bits)



Jun/20/2023 EX9000A/AB series:

EX9052A-MTCP
Modbus TCPIP to DI*8(Dry Contact; Isolation) & DO*8(Open Drain(P-MOSFET); Isolation)& DIO Synchronization (Mirror
EX9052AB-MTCP
Modbus TCPIP to DI*8(Dry/Wet Contact; Isolation) & DO*8(Open Drain(P-MOSFET); Isolation)& DIO Synchronization (Mirror Local DI to DO) & Auto-Off Time of digital output
EX9060A-MTCP
Modbus TCPIP to DI*5(Dry/Wet Contact; Isolation) & 3 Relay(0.6A@125VAC; 2A@30VDC)Output(Form A(RL1); Form C(RL2&RL3))& DIO Synchronization (Mirror Local DI to DO) & Auto-Off Time of digital output
EX9061A-MTCP
Modbus TCPIP to DI*6(WetContact; Isolation) & 6 Relay(0.6A@125VAC; 2A@30VDC)Output(Form A)
EX9063A-MTCP
Modbus TCPIP to DI*7(Dry/Wet Contact; Isolation) & 3 Relay(5A@250VAC; 5A@30VDC)Output(Form A)& DIO Synchronization (Mirror Local DI to DO) & Auto-Off Time of digital output
EX9066A-MTCP
Modbus TCPIP to DI*6(WetContact; Isolation) & 6 Relay(5A@250VAC; 5A@30VDC)Output(Form A)



Dec/5/2019 Open Frame 8” - 23” Touch Panel + Intel CPU Board for OEM/ODM Customers:



Dec/3/2019 EX9786-RPC (Raspberry PI Embedded
w/ADIO/UART/USB/ Mini PCIe/HDMI/SD/TCPIP/SIM/GPIO):



Dec/27/2018 Intelligent universal controller & CTM(Mini SCADA)
Application In Hospital

Application for Cold Chain/Freezer
Remote IO(WiFi/Ethernet/RS485) & CTM(Mini SCADA)



May/15/2018 EX9212-LoRa-S(RS232/485/422)/E(Ethernet)/U(USB)/DIO(Digital I/O)
It can extent the data transmission distance to 5km or more
EX9212LoRa-E
EX9212LoRa-S
EX9212LoRa-USB
EX9212LoRa-DIO



Apr/20/2018 Dual Lan Ethernet IO w/ Daisy Chain & Auto-Bypass Protection:
EX9200 Series: Digital IO / Relay IO

EX9250
10 isolated DI & 6 open collector DO with ModbusTCP daisy chain module






 Mar/12/2018 EX Cloud Demo for Rasberry PI and PIC
Enter your email: Sys@t.com
Enter your password: 123456
For PIC Embedded Controller

- Power BI to sign-in then login by
Enter your email: support@topsccc.com
Enter your password: Picex9018bl-m
For Raspberry PI Embedded Controller





 Feb/06/2017 EX91307
• Intel 4-core Bay Trail N2930 / J1910 CPU
• SO-DIMM Support DDR3 800, up to 8GB
• DVI-I: Integrated 7th Intel Graphics support
• DX11, OGL3.2, max. 1920x1200 resolution
• 24-bit LVDS: max. 1920x1200
• SATA2: SATA2 x 1, mSATA x 1
• Audio
• Gigabit LAN x 2
• mini-PCI socket x 2
• COM x 4 (RS-232/422/485x1 + RS-232x3)
• USB3.0 x 1, USB2.0 x 6
• GPIO x 8
• +9V ~ +24V DC-IN

EX91761
• Intel LGA 1151 Socket Core i7/i5/i3/Pentium Processor
• SO-DIMM SO-DIMM DDR3L 1333/1066MHz * 2 (Max 16GB)
• 2.5” SATA HDD * 1 (Support RAID-1)
• HDMI * 1
• COM * 1 (RJ-45 type)
• GPIO * 1 (optional)
• USB 3.0 * 2
• USB 2.0 * 2 (optional)
• Giga LAN * 8
• Full size Mini-PCIE * 1
• SIM Card Slot * 1
• Support TPM (optional)
• Audio
• +9V ~ +24V DC-IN
